Square Motor DC-150A
Category:Automatic door
Release date:2018-04-16 17:04:41

Features and Functions

  The new automatic doors,the use of modern Design,application of high-power brushless global trust Motorand new mechanical set up,hanging pieces (frame) lmported high-strength nylon,the unit load up 2* 120kg.The new unit has been designed by Number of tests.For a variety of large-scale channel Indutrial plants  and other places,smooth operation,security Easy to install,easy to maintain.

Technical Data

• Doorforms: single door /double door
• Load capacity: ≤ 1* 150 kg,≤  2* 120kg
• Leaf width :700-1300mm,600-1200mm
• Power supply voltage: AC220V 士10%,50-60Hz
• Power consumption: <70W
• Opening speed :200-450mm /S (Adjustable)
• Closing speed :200-450mm /S (Adjustable)
• Hours :0-9S (adjustable)
• Manual opening force: <40N <50N
• Running noise: < 550Db
• Ambient temperature:-20~+50℃
• Sensor Type: sensors for a variety of modes
